Steel Forged Trunnion Ball Valve

Steel Trunnion Ball Valve Forged Trunnion utitur ver-onusto mechanismo sede, quae praecipuum munus agit in compensatione induendi quae naturaliter accidit super tempus. Cum plectrum saepius operatum est, sedem evellere vel debilitare incipit. Ver-onusta sedes efficit ut obsignationis integritas servetur, lacus praecaveatur et certa signatio perficiendi per vitam plectrum inserviat. Haec valvae pila egregiam obsignationem observantiam sub alto et humili pressione condiciones servare potest. Sedes consilio et cura fabricandi curam habet ut sigillum strictum cuiuscumque pressionis ambigua intra systema providere possit. Utrum alta pressura pipelines tractat an lineas distributio humilis pressio, valvae efficere potest ut lacus fluidus minimizetur, ita ut perficiat salutem et ratio integritatem.

Contactus Us

PREV: Nullus prior articulum DEINDE: Nullus proximus articulum

Describe
Parameter

Describe

●Operating pressionem usque ad: 10,000 psig (413 talea)
● caliditas operans: -65 ad 450 °F (-54 ad 232°C)
Ver-onusto sedem compenset conterentes
High pressura et humilis pressura sunt bona cione perficientur
Imo oneratione caulis prohibet derivantur
Humilis torques operating, donec servitium vitae
Gravis-officium manubrio indicant fluxus directionem
●Manual, electrica vel pneumatica actus praesto sunt
Solum ostium -Tee solum

Parameter

Basic Ordering Numerus	Connection Typus et Location	Orificium in. (mm)	Cv	Dimensio, m. (mm)
Basic Ordering Numerus	Connection Typus et Location	Orificium in. (mm)	Cv	A	B	C	D	E	F
-TB-FT4-5-3W	1/4 Tube	0.19 (4.8)	0.75	4.09 (103.8)	2.04 (51.9)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)
-TB-FT6-5-3W	3/8 Tube	0.19 (4.8)	0.75	4.25 (108)	2.13 (54.0)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)
-TB-FT8-5-3W	1/2 Tube	0.19 (4.8)	0.75	4.60 (11.8)	2.30 (58.4)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)

-TB-MT4-5-3W	6mm Tube	0.19 (4.8)	0.75	4.09 (103.8)	2.04 (51.9)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)
-TB-MT8-5	8mm Tube	0.19 (4.8)	0.75	4.14 (105.2)	2.07 (52.6)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)
-TB-MT10-5	10mm Tube	0.19 (4.8)	0.75	4.25 (108)	2.13 (54.0)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)
-TB-MT12-5	12mm Tube	0.19 (4.8)	0.75	4.60 (11.8)	2.30 (58.4)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)
TBH-FT4-5-3W	1/4 Tube	(4.8)	0.75	4.09 (103.8)	2.04 (51.9)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)
-TBH-FT6-5-3W	3/8 Tube	0.19 (4.8)	0.75	4.25 (108)	2.13 (54.0)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)
-TBH-FT8-5-3W	1/2 Tube	0.19 (4.8)	0.75	4.60 (11.8)	2.30 (58.4)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)

-TBH-MT4-5-3W	6mm Tube	0.19 (4.8)	0.75	4.09 (103.8)	2.04 (51.9)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)
-TBH-MT8-5-3W	8mm Tube	0.19 (4.8)	0.75	4.14 (105.2)	2.07 (52.6)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)
-TBH-MT10-5-3W	10mm Tube	0.19 (4.8)	0.75	4.25 (108)	2.13 (54.0)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)
TBH-MT12-5-3W	12mm Tube	0.19 (4.8)	0.75	4.60 (11.8)	2.30 (58.4)	1.06 (26.9)	1.88 (47.7)	1.57 (40.0)	2.56 (65.0)
